SUPERMICRO mini1U chassis 2x internal Drive Bays 2,5", 350W (Platinum) Front IO
Obrázky mají pouze informativní charakter a mohou se lišit od skutečnosti.

Supermicro mini1U chassis 2x internal Drive Bays 2,5", 350W (Platinum) Front IO

 Serverový konfigurátor Key Features Support STD and WIO MB Optional Up to 4 x 2.5" fixed with bracket, Up to 1 x 3.5" fixed drive bay 1U 350W Multi-output power supply Platinum level Up to , 2 full height expansion slot(s) 4 x 40x56mm PWM fan(s) Optional 2 x fans for AOC cooling Product SKUs…
Kategorie: Příslušenství
Kód: 3164649PN: CSE-515-350Výrobce: SupermicroZáruka: 6 měsíců
Výrobek pochází z oficiální české distribuce.
Aktuálně není v nabídce

Popis produktu

 Serverový konfigurátor

Key Features

  1. Support STD and WIO MB
  2. Optional Up to 4 x 2.5" fixed with bracket, Up to 1 x 3.5" fixed drive bay
  3. 1U 350W Multi-output power supply Platinum level
  4. Up to , 2 full height expansion slot(s)
  5. 4 x 40x56mm PWM fan(s)
  6. Optional 2 x fans for AOC cooling
Product SKUs
CSE-515-350
  • SuperChassis 515-350

Form Factor
  • Support STD and WIO MB

Processor Support
  • Dual and Single Intel® and AMD processors

Dimensions
Height
  • 1.7" (43 mm)
Width
  • 17.2" (437 mm)
Depth
  • 16.9" (429 mm)
Gross Weight
  • 16 lbs (7.26 kg)
Packaging (W x H x L)
  • 27" (686 mm) x 8" (203 mm) x 24" (610 mm)
Available Color
  • No Paint

Expansion Slots
  • Up to
  • 2 full height expansion slot(s)

Drive Bays
  • Optional Upto 4 x 2.5" fixed with bracket
  • Upto 1 x 3.5" fixed drive bay

Front Panel
Buttons
  • Power On/Off button
  • System Reset Button
LEDs
  • 2 Network Activity LEDs
  • Fan Fail/System Over Heat LED
  • HDD activity LED
  • Power Status LED
Motherboard (for CSE- 515-350)
X10SRM-TF X10SRM-F
X11SPi-TF X11SSW-4TF
X11SSW-TF X11SPL-F
X11SPM-TF X11SPM-TPF
X11SPM-F H11SSL-NC
H11SSL-C H11SSL-i
X11SCM-F X11SCM-LN8F
X11SCL-LN4F


Systems Cooling
Fans
  • 4 x 40x56mm PWM fan(s)
  • Optional 2 x fans for AOC cooling

Operating Environment (System)
Operating Temperature Range
  • 5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range
  • -40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
  • 8% - 90% (non-condensing)
Non-Operating Relative Humidity Range
  • 5% - 95% (non-condensing)

Power Supply
1U 350W Multi-output power supply Platinum level
Power Efficiency
  • 93%
Total Output Power and Input
  • 350W with Input 100 - 240Vac
AC Input Frequency
  • 50-60Hz
Dimensions (L x W x H)
  • 180 x 100 x 40 mm
Output Type
  • 24pin ATX
-12V
  • Max: .2A / Min: 0A
+12V
  • Max: 29A / Min: .5A (100Vac - 240Vac)
+5V
  • Max: 15A / Min: .2A
+3.3V
  • Max: 12A / Min: .2A
+5Vsb
  • Max: 3A / Min: 0A
Certification
  • Platinum Certified  Platinum Certified

Regulatory (Power Supply)
Power Supply Safety / EMC
  • BSMI
  • CCC
  • CE/EMC
  • FCC class B
  • TUV/CB

Parametry

Provedení1U
