Elegant & Compact (Vertical/Horizontal) Desktop in grey-silver
finishing
- Easy-to-install owing to user-friendly pivot mechanism
- Offers USB Type C to front panel
This semi tool-free mATX chassis combines a modern and life-style
appearance with the highest possible functionality, offering
amongst many other features, an extreemly user-friendly pivot
mechanism which allows easy access and semi tool-free installation
of the drives. The modern and highly presentable front panel offers
a USB Type C as well as other relevant connectors. A perfect choice
for both home and/or office PC solutions with class.
Specifications:
| Model | BS-10G |
| EAN code | 0753263075680 |
| Color | Silver grey |
| Material | 0,8mm SGCC |
| Motherboard support | Mini ITX, mATX (max. 244mm x 220mm) |
| Dimension (DxWxH) | 290mm x 145mm x 343mm (Stand +2mm) |
| Weight (without/with package) | 3,5 kg / 4,5 kg |
| Drive bay external | 1x 5,25“ ultra slim ODD |
| Drive bay internal | 1x 3,5“ and 1x 2,5“ / 2x 2,5“ (anti vibration rubber) |
| Power supply | GPF-300P (TFX) |
| Front I/O | 2x USB3.0, 2x USB2.0, Mic-in, Audio-out (AZALIA / HD-Audio), 1xUSB Type C (480 Mbit/s) |
| Scope of delivery | Set of screws, anti vibration rubber (for HDD/SSD) |
| Expansion slots | 4 |
| Cooling Compatibility | 1x 80mm at the rear |
| CPU cooler height (max.) | 120mm |
| VGA card length (max.) | 250mm |
| Warranty | 24 Months |
| Barva skříně | Černá |
|---|---|
| Počet pozic 2.5" (SSD) | 1 |
| Počet pozic 3.5" (HDD) | 1 |
| Počet pozic 5.25" | 1 |
| Provedení skříně | Mini Tower / micro ATX |
| Vybavení PC skříně | S integrovaným zdrojem |
| Vybavení PC skříně | Přední Audio panel |
| Vybavení PC skříně | Přední USB panel |
| Výkon zdroje (ve W) | 300 |
