| Chipset | AMD A68H |
| CPU SUPPORT | AMD FM2+ A-series APU Maximum CPU TDP (Thermal Design Power) : 100Watt ? Please refer to www.biostar.com.tw for CPU support list. |
| MEMORY | Support Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/
2400(OC)/ 2600(OC) MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory ?Please refer to www.biostar.com.tw for Memory support list. |
| INTEGRATED VIDEO | By CPU model Supports DX12 Supports HDCP AMD Dual Graphics Technology |
| STORAGE | 4 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10 |
| LAN | Realtek RTL8111H - 10/100/1000Mb/s Controller |
| AUDIO CODEC | Realtek ALC662 6-Channel HD Audio |
| USB | 2 x USB 3.2 Gen1 Port (5Gb/s) (2 on rear I/Os) 6 x USB 2.0 Port(2 on rear I/Os and 4 via internal headers) |
| EXPANSION SLOT | 1 x PCI-E 3.0 x16 Slot 1 x PCI-E 2.0 x1 Slot |
| REAR I/O | 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB 3.2 Gen1 (5Gb/s) Port 2 x USB 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x LAN Port 3 x Audio Jacks |
| INTERNAL I/O | 2 x USB 2.0 Header(each header supports 2 USB 2.0 ports) 4 x SATA III Connector (6Gb/s) 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Connector 1 x System Fan Connector 1 x 4-Pin Power Connector 1 x 24-Pin Power Connector 1 x Clear CMOS Header |
| H/W MONITORING | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring |
| DIMENSION | Micro ATX Form Factor Dimension: 21.5 cm x 17 cm ( W x L ) |
| OS SUPPORT | Supports Windows XP/ 7/ 8/ 8.1(64bit)/ 10(64bit) ?Biostar reserves the right to add or remove support for any OS with or without notice. |
| BUNDLE SOFTWARE | BullGuard |
| ACCESSORIES | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
| Caution!! The specification and pictures are subject to change without notice! | |
| PCI Express x1 | 1 |
|---|---|
| PCI Express x16 | 1 |
| Počet paměťových slotů | 2 |
| Typ paměti | DDR3 |
| Integrovaná grafická karta | NE |
| Čipová sada | AMD A68H Chipset |
| Patice (CPU Socket) | FM2+ |
| Počet CPU socketů | Single socket |
| Výrobce čipsetu | AMD |
| Formát | mATX |
| Herní | ANO |
| Určení | Hraní a multimedia |
| Určení | Kancelář/domácnost |
